Sophos XGS 3100 Next-Gen Firewall with Xstream Protection, 5-Year (US Power Cord)
Sophos XGS 3100 Next-Gen Firewall with Xstream Protection, 5-Year (US Power Cord)
Couldn't load pickup availability
Powerful Protection and Performance
Sophos Firewall and the XGS Series appliances with dedicated Xstream Flow Processors enable the ultimate in application acceleration, high-performance TLS inspection, and powerful threat protection.
XGS 3100 Featured Specifications
Firewall Throughput: 38,000 Mbps
Firewall IMIX: 22,000 Mbps
IPS Throughput: 9,820 Mbps
Threat Protection Throughput: 2,000 Mbps
Ethernet interfaces (fixed): 8 x GE copper, 2 x SFP fiber*, 2 x SFP+ 10 GbE fiber*
* Transceivers (mini GBICs) sold separately
Number of Flexi Port slots: 1
Protection Bundle Included: Xstream Protection
Sophos Next-Generation Firewalls
Sophos XGS Series Appliances
All XGS Series firewall appliances are built upon a dual-processor architecture, combining a high-performance, multi-core CPU with a dedicated Xstream Flow Processor for targeted acceleration at the hardware level. This gives you all the flexibility and adaptability of an x86 based firewall plus a significant performance boost over legacy firewall designs.
TLS 1.3 Inspection
According to the latest statistics, approximately 90% of web traffic is encrypted, making it invisible to most firewalls. An increasing amount of malware and potentially unwanted apps exploit the fact that organizations are simply not using SSL inspection. Network administrators' main fears are that SSL inspection will have a performance impact or cause something to break, impacting the user experience.
Sophos Firewall removes the blind spots caused by traffic by allowing you to use SSL inspection while maintaining performance efficiency.
Deep Packet Inspection
We believe you should never have to decide between security and performance. Sophos Firewall includes a highspeed deep packet inspection (DPI) engine to scan your traffic for threats without a proxy slowing down the process. The firewall stack can completely offload the processing to the DPI engine, significantly reducing latency and so improving overall efficiency.
Sophos Firewall blocks the latest ransomware and breaches with high-performance streaming DPI including next-gen IPS, web protection, and app control, as well as deep learning and sandboxing powered by SophosLabs Intelix.
Application Acceleration
A significant portion of your network traffic is important business application traffic destined for branch offices, remote users, or cloud application servers. This trusted traffic, which needs no additional security scanning for threats or malware, can be intelligently directed to the FastPath, reducing latency, and optimizing overall performance. This provides added capacity and headroom for traffic that does need deep packet inspection.
Sophos Firewall accelerates your SaaS, SD-WAN, and cloud traffic such as VoIP, video, and other trusted applications automatically or via your own policies - putting them on
Xstream Protection Bundle Specifications
|
Xstream Protection Bundle: |
|
|
Base License |
Networking, Wireless, Xstream Architecture, Unlimited Remote Access VPN, Site-to-Site VPN, reporting |
|
Network Protection |
Xstream TLS and DPI engine, IPS, ATP, Security Heartbeat, SD-RED VPN, reporting |
|
Web Protection |
Xstream TLS and DPI engine, Web Security and Control, Application Control, reporting |
|
Zero-Day Protection |
Machine Learning and Sandboxing File Analysis, reporting |
|
Central Orchestration |
SD-WAN VPN Orchestration, Central Firewall Advanced Reporting (30-days), MTR/XDR ready |
|
Enhanced Support |
24/7 support, feature updates, advanced replacement hardware warranty for term |
XGS 3100 Detailed Specifications
|
Performance |
XGS 3100 |
|
|
Firewall throughput |
38,000 Mbps |
|
|
Firewall IMIX |
22,000 Mbps |
|
|
Firewall Latency (64 byte UDP) |
4 μs |
|
|
IPS throughput |
9,820 Mbps |
|
|
Threat Protection throughput |
2,000 Mbps |
|
|
NGFW |
9,000 Mbps |
|
|
Concurrent connections |
12,260,000 |
|
|
New connections/sec |
186,500 |
|
|
IPsec VPN throughput |
5,200 Mbps |
|
|
Xstream SSL/TLS Inspection |
2,470 Mbps |
|
|
Xstream SSL/TLS Concurrent connections |
55,296 |
|
|
Physical interfaces |
|
|
Storage (local quarantine/logs) |
Integrated min. 240 GB SATA-III SSD |
|
Ethernet interfaces (fixed) |
8 x GE copper 2 x SFP fiber* 2 x SFP+ 10 GbE fiber* |
|
Bypass port pairs |
1 |
|
Management ports |
1 x RJ45 MGMT 1 x COM RJ45 1 x Micro-USB (cable incl.) |
|
Other I/O ports |
2 x USB 3.0 (front) 1 x USB 2.0 (rear) |
|
Number of Flexi Port slots |
1 |
|
Flexi Port modules (optional) |
8 port GbE copper 8 port GbE SFP fiber 4 port 10 GbE SFP+ fiber 4 port GbE copper bypass (2 pairs) 4 port GbE copper PoE + 4 port GbE copper 4 port 2.5 GbE copper PoE 2 port GbE Fiber (LC) bypass + 4 port GbE SFP Fiber |
|
Max. total port density (incl. use of modules) |
20 |
|
Max. Power-over-Ethernet (using Flexi Port module) |
1 module: 4 ports, 60W max. |
|
Optional add-on connectivity |
SFP DSL module (VDSL2) SFP/SFP+ Transceivers |
|
Display |
Multi-function LCD module |
* Transceivers (mini GBICs) sold separately
|
Physical specifications |
|
|
Mounting |
1U rackmount (2 rackmount ears included) |
|
Dimensions Width x Height x Depth |
438 x 44 x 405 mm |
|
Weight |
4.7 kg/10.36 lbs (unpacked) 7 kg/15.43 lbs (packed) |
|
Environment |
|
|
Power supply |
Internal auto-ranging DC 100-240VAC, 3-6A@50-60 Hz External Redundant PSU Option |
|
Power consumption |
3100: 50 W/170.77 BTU/hr (idle) 3300: 50 W/170.77 BTU/hr (idle)3100: 182 W/621.97 BTU/hr (max.) 3300: 201 W/686.68 BTU/hr (max.) |
|
PoE addition enabled |
76 W/260 BTU/hr (max.) |
|
Operating temperature |
0°C to 40°C (operating)-20°C to +70°C (storage) |
|
Humidity |
10% to 90%, non-condensing |
|
Product Certifications |
|
|
Certifications |
CB, CE, UL, FCC, ISED, VCCI, CCC, |
-
