Sophos

Sophos SD-RED 20 Rev.1 Appliance - with multi-region power adapter

Sophos SD-RED 20 Rev.1 Appliance - with multi-region power adapter

Regular price $565.57
Regular price Sale price $565.57
Sale Sold out
Shipping calculated at checkout.

SD-RED 20

Sophos SD-RED: Empowering your SD-WAN strategy

Sophos has long been a pioneer in providing an easy-to-use, secure way to connect branch offices and other remote locations. Sophos Firewall includes a number of SD-WAN features to help you to accelerate application performance and get better visibility into network health to ensure that your remote locations enjoy the same performance as your main office.


SD-RED devices are built on the latest enterprise-class, high-speed networking platforms. They work with your Sophos Firewall whether you’ve deployed as hardware, software or in the public cloud. Sophos’s full range of Sophos Wireless Access Points are also compatible with Sophos SD-RED. You can use Sophos SD-RED with just the Base License included in your appliance purchase, however, you will need an active Network Protection subscription for management.


SD-RED 20 Featured Specifications:


Maximum throughput: 250 Mbps

LAN interfaces: 4 x 10/100/1000 Base-TX (1 GbE copper)

WAN interfaces: 1 x 10/100/1000 Base-TX (shared with SFP)

SFP interfaces: 1x SFP fiber (shared port with WAN)

Power-over-Ethernet ports: None



SD-RED 20 Detailed Specifications

Model

SD-RED 20

Capacity

Maximum throughput

250 Mbps


Physical interfaces (Built-in)

LAN interfaces

4 x 10/100/1000 Base-TX (1 GbE copper)


WAN interfaces

1 x 10/100/1000 Base-TX (shared with SFP)


SFP interfaces

1x SFP fiber (shared port with WAN)


Power-over-Ethernet ports

None


USB ports

2 x USB 3.0 (front and rear)


COM ports

1 x micro-USB


Optional Connectivity

Modular bay

1 (for use with optional Wi-Fi OR 4G/LTE card)


Optional Wi-Fi module

802.11 a/b/g/n/ac Wave 1 (Wi-Fi 5) dual-band capable2 x 2 MIMO 2 antennas


Optional 3G/4G LTE module

MC7430/MC7455 Sierra Wireless Card

Optional VDSL modem

Optional SFP modem (support coming in future release)

Physical Specifications

Dimensions

Width x Height x Depth

225 x 44 x 150 mm 8.86 x 1.73 x 5.91 inches


Weight

0.9 kg/1.8 kg (1.98 lbs/3.97 lbs) Unpacked/Packed


Power supply adapter

AC Input: 110-240VAC @50-60 HzDC Output: 12V +/- 10%, 3.7A, 40W

Power redundancy support

Yes, optional second power supply


Power consumption

6.1W, 20.814 BTU (idle)22.6W, 77.114 BTU (full load)


Temperature (operational)

0°C to 40°C (32°F to 104°F)


Temperature (storage)

-20°C to 70°C (-4°F to 158°F)



Humidity

10% to 90%, non-condensing


Certifications (safety, EMC, radio)

CE/FCC/IC/RCM/VCCI/CB/UL/CCC/KC/ANATEL
